Monitors

• 17.3" LCD panel, 1920 x 1080 resolution
• 2 x 2K/3G/HD/SD-SDI, HDMI monitoring
• Y/Pb/Pr, VGA, CVBS monitoring
• 16-channel embedded audio meters with alerts
• Select any two audio channels to output
• Supports video analysis assistant patterns such as waveform Y/Cb/Cr/R/G/B and single line, vectorscope, & histogram R/G/B/Y
• Peaking focus assist (red/blue switch)
• AFD, timecode, H/V delay
• TSL UMD and text Tally display
• Safety marker 4:3/13:9/14:9/15:9/1.85:1/2.35:1
• False color, R/G/B/Mono, zebra stripes, internal color bar
• V-mount battery plate
• 19" rack install, 7U height
• USB firmware upgrade

› 7-inch IPS LCD, 1920×1200 FHD

› 3000nit super bright, sunlight visible

› PQ/HLG HDR monitoring

› HDMI 1.4 (4K30p) input and loop out

› 2x 4x Quick zoom-in and Pan

› Peaking focus assist and precision adjust

› Waveform / Vector / Histogram

› Build-in 30 kinds of De-log 3DLUTs

› User DIT 3DLUT import by SD card

› 2-ch HDMI audio meters display

› Super False color, Zebra stripes, Anamorphic

› Built-in NP-F plate, V-mount for option

• 3000 cd/m² Outdoor High Brightness
• 1920 x 1200 IPS LCD Screen
• HDMI/3G-SDI Input and Loop Output
• Up to DCI 4K30 Input via HDMI
• 3.5mm Audio Output
• Single Joystick Menu Control
• Eight UI Layouts with Shortcut Buttons
• Up to 4x Zoom-In and Image Scroll
• Integrated L-Series Battery Plate
• V-Mount Plate and Power Adapter Included

• 1920 x 1080 Native Resolution
• HDMI 4K Input
• 1400:1 Contrast, 460 cd/m² Brightness
• Calibrated for Rec. 709 HD Color

• 7" 1920 x 1200 IPS LCD Monitor
• HDMI 1.4 and 3G-SDI Loop-Through I/O
• Accepts SD, HD, and UHD 4K Video
• 2200 cd/m² Brightness

• Touchscreen 1920 x 1080 Display
• Up to DCI 4K HDMI Input; HDMI Output
• LUT Support via SD Card Slot
• DC, USB, L-Series/LP-E6 Power Support

• 1920 x 1200 Resolution, 450 cd/m²
• Brightness Histogram
• Peaking Focus Assist (Red, Green, Blue)
• False Colors & Zebra Exposure Tools

• 1920 x 1080 Touchscreen Display
• 10-Bit Exterior Viewable Monitor
• 4K HDMI Input
• 1000 cd/m² Brightness

• 7" 1920 x 1200 Touchscreen LCD
• Record up to DCI or UHD 4K HDR Video
• HDMI and 12G-SDI Video Inputs & Outputs
• 10-Bit, 4:2:2 ProRes & DNxHD Encoding
