Sony FR7 Cinema Line PTZ Camera

Out of stock
SKU
ILME-FR7
AED 38,062.50 AED 36,250.00
Pre-Order to secure your piece
  • Supports up to UHD 4K120 Video
  • Sony E-Mount Lens Interchangeability
  • 4K Full-Frame Sensor
  • 12G-SDI, HDMI & Streaming Output
  • Variable Electronic ND Filter
  • Smooth, Slow Pan & Tilt Movement
  • IR, IP & Web App Remote Control
  • Flexible PoE+ Installation
  • Genlock, Timecode & Tally Lamps

Sony ILME-FR7 Overview

Capture cinematic, full-frame footage in PTZ form for broadcast use, reality shows, houses of worship, and live events and sports with the black FR7 Cinema Line PTZ Camera from Sony. This versatile camera features the unique ability to use interchangeable Sony E-mount lenses and is currently compatible with up to 70 E-mount lenses ranging from 12 to 1200mm. The large image sensor provides 15+ stops of dynamic range, captures up to UHD 4K120 video, offers live streaming, supports S-Cinetone, Cine EI, and MLUT looks for matching select Sony cameras, and enables you to create shallow depth-of-field bokeh effects.

The FR7 PTZ camera features flexible PoE++ (Power-over-Ethernet) installation, up to 100 preset positions, tally lamps, a built-in electronic ND filter, 5-pin XLR audio input, and multicamera functions like timecode and Genlock. Versatile control options include an IR remote, compatibility with controllers like the Sony RP-IP500, and a remote web app for tablets and computers.

Expressive 4K Imaging
Full-Frame Sensor
  • The FR7 combines a 4K full-frame sensor and compatibility with Sony E-mount lenses to produce outstandingly expressive, cinematic imagery
  • 15+ stops of dynamic range and a base ISO of 800 that is expandable from 12,800 to 409,600 for capturing optimal video in an array of lighting conditions
Sony E-Mount
  • Compatibility with up to 70 Sony E-mount lenses covers a range of 12 to 1200mm, enabling you to capture the widest vistas and the closest details
  • Use with G Master (GM) lenses to obtain impressive resolution and pleasing bokeh
Imaging Functions
Capture rich detail and wide color using Sony S-Log3 and create nuanced contrast with Hybrid Log Gamma (HLG)
Built-In ND Filters
  • An integrated, electronic ND filter offers variable ND filtration ranging from 1/4 (2 stops) to 1/128 (7 stops)
  • Use the ND filter to compensate for changes in exposure without affecting your depth of field
  • Create shallow depth-of-field effects by adding the ND and opening the iris
SDI Raw Output
The FR7 can output raw video via the SDI (BNC) output to an external recording for color grading and other post-production tweaking
UHD 4K 120p Recording
Record UHD 4K video at rates up to 120 fps for slow-motion effects
Remote & Robotics Functions
IP Control
Use the IP remote function to control your camera from a distance like a broadcast truck and/or to control multiple cameras
Smooth Movement
Slow, smooth pan and tilt movements enable you to unobtrusively zoom in on the action and reframe accordingly
Video Output & Streaming
  • Output video using the HDMI and up to 12G-SDI video outputs
  • Stream RTSP, SRT, or NDI|HX (requires NewTek license) using the LAN port
Control Options
  • The included IR remote can be used for pan, tilt, zoom (PTZ), focus, recording, playback, and other camera settings
  • Use with the separately available RM-IP500 control panel with joystick zoom rocker, and buttons
  • Web app remote control can be accessed from a tablet or PC browser
Mounting
  • Mount on a tripod or riser using the two 1/4"-20 threads
  • Use the optional mount to attach the FR7 camera to a ceiling
  • Attach camera accessories using the 15mm rod mounts
Cinematic Multicamera Use
Cine-Style Capture
  • Bring a cinematic look to your PTZ capture and match footage from other Sony cameras with the S-Cinetone picture profile
  • The Cine EI mode with MLUT management can be used with S-Log3 or raw recording
  • XAVC recording with metadata capture supports up to 10-bit, 4:2:2 color and HDR recording
Hybrid Autofocus
Fast hybrid autofocus with face detection and touch tracking enable you to keep even dynamic action in focus
Up to 100 Presets
Quick control with up to 100 preset positions
Interfaces
  • A robust interface includes a LAN port for network and PoE++ use, timecode input, a genlock connector, and red/green tally indicators
  • Dual media slots are compatible with both CFexpress Type A and SDXC memory cards
get real warranty on Sony FR7 Cinema Line PTZ Camera at Digi Tech Trading LLC
It's always easy to shop for PTZ Cameras at Digi Tech Trading LLC because you can browse by best sellers, brand, price range, customer rating, or special offers. And you can take advantage of free shipping within UAE. Digi Tech Trading LLC Sony FR7 Cinema Line PTZ Camera - your trusted source of filmmaking equipments
More Information
Manufacturer Sony

Sony ILME-FR7 Specs

Imaging
Lens MountSony E
Sensor TypeCMOS Sensor
Sensor ResolutionActual: 12.9 Megapixel
Effective: 10.3 Megapixel
Lens CommunicationYes, with Autofocus Support
Built-In ND Filter2 to 7 Stop Electronic ND Filter
Focus ControlAutofocus
Autofocus PointsPhase Detection: 627
Exposure Control
Shutter TypeElectronic Rolling Shutter
Shutter Speed1/8000 to 1 Second
ISO Sensitivity800 to 12,800 (Extended: 409,600)
Gain-3 to 30 dB
Advertised Dynamic Range15 Stops
Flip / Mirror SupportImage Flip
White Balance2000 to 15,000K
Presets: ATW, Set A
Video Capture
External Recording ModesRaw 16-Bit via SDI/BNC
4096 x 2160 at 23.98p/24.00p/25p/29.97p/50p/59.94p
3840 x 2160 at 23.98p/25p/29.97p/50p/59.94p
1920 x 1080 at 23.98p/24.00p/25p/29.97p/50i/50p/59.94i/59.94p
HDMI
4096 x 2160 at 23.98p/24.00p/25p/29.97p/50p/59.94p
3840 x 2160 at 23.98p/25p/29.97p/50p/59.94p
1920 x 1080 at 23.98p/24.00p/25p/29.97p/50i/50p/59.94i/59.94p
720 x 480 at 59.94p
720 x 576 at 50p
Internal Recording ModesXAVC-I 4:2:2 10-Bit
DCI 4K (4096 x 2160) at 23.98p/24.00p/25p/29.97p/50p/59.94p [240 to 600 Mb/s VBR]
UHD 4K (3840 x 2160) at 23.98p/25p/29.97p/50p/59.94p [240 to 600 Mb/s VBR]
1920 x 1080 at 23.98p/25p/29.97p/50p/59.94p [89 to 222 Mb/s]
XAVC-L
UHD 4K (3840 x 2160) at 23.98p/25p/29.97p/50p/59.94p [100 to 150 Mb/s VBR]
1920 x 1080 at 23.98p/25p/29.97p/50p/59.94p [35 to 50 Mb/s VBR]
Audio Recording4-Channel 24-Bit 48 kHz LPCM Audio
Gamma CurveHDR-HLG, Rec709, S Cinetone, Sony S-Log 3, Standard
IP StreamingNDI|HX, RTSP, SRT: 640 x 360 to 4096 x 2160 (0.5 to 80.00 Mb/s)
Control
Presets3 via IR
100 via IP
Move SpeedPan: 0.02 to 60°/sec
Tilt: 0.02 to 60°/sec
Movement RangePan: 340° (-170 to 170°)
Tilt: 225° (-30 to 195°)
Tally LightYes
Supported Control ProtocolsIR
VISCA
Interface
Media/Memory Card SlotDual Slot: CFexpress Type A / SD
Video I/O1 x BNC (12G-SDI) Output
1 x SFP+ Output
1 x HDMI Output
Audio I/O1 x XLR 5-Pin Mic/Line (+48 V Phantom Power) Input
Other I/O1 x BNC (Timecode)
1 x RJ45 (LAN) Control
1 x BNC (Genlock)
1 x RJ45 (Tally)
Power
PoE SupportPoE++ 802.3bt
Power I/O1 x Barrel (19.5 VDC) Input
Power ConsumptionPoE: to 71.3 W
Power Supply: to 80 W
Environmental
Operating Temperature32 to 104°F / 0 to 40°C
Storage Temperature-4 to 140°F / -20 to 60°C
General
Mounting2 x 1/4"-20 Female for Tripod
Sound LevelNC35
Dimensions (W x H x D)11.4 x 9.2 x 8.9" / 289 x 233 x 227 mm (Without Protrusions)
Weight10.1 lb / 4.6 kg (Body Only)
  • Sony FR7 Cinema Line PTZ Camera
  • RMT-RC1 Remote Commander
  • Lens Mount Cap for Body
  • AC Adapter
  • Power Cord
  • HDMI Cable Clamp
  • Limited 1-Year Warranty

Not in the Box

  • Essential Lenses (Not Included)
Sony FR7 Cinema Line PTZ Camera
